ALMAS DARYA 2

Flat Top Deck Cargo Barge

GENERAL

• Year Built: 2006

• Flag / Port of Registry: Iran / Bandar Abbas

• Official Number: 12911

• Class / Classification: Asia Classification Society (ACS)

• GRT / NRT: 4,466 t / 1,339 t

DIMENSIONS

• Length Overall: 280 ft (85.34 m)

• Breadth: 90 ft (27.43 m)

• Depth Loaded: 18 ft (5.50 m)

• Draft Loaded: 14.5 ft (4.39 m)

• Deadweight: 8,000 t (approx.)

• Deck Loading: 15 t/m²

• Transverse Bulkhead: Eight (8)

• Longitudinal Bulkhead: Two (2)

DECK EQUIPMENT

• Anchor Winch: 1 × hand-operated emergency anchor winch

• Anchor: 1 × 2,100 kg stockless bower anchor

• Smit Brackets: 4 × smit towing brackets – port & starboard, forward and aft

• Stanchions: 26 stanchions on each side

• Navigation Lights: 1 set solar type, port & starboard at forward and aft

• Mooring Bollards: 4 sets of double mooring bollards each side (deck)

OTHER DETAILS

The barge is of all-welded steel construction with a flat-top deck, designed for heavy cargo transport and offshore operations.
It provides stable deck space for large equipment, containers, or construction materials and is suitable for operations within regional and offshore waters.

Disclaimer

Particulars are believed to be correct but not guaranteed.
Owners reserve the right to amend the specifications without prior notification.
All particulars are given without warranty as to correctness.
Interested parties should inspect the vessel’s certificates, drawings, or conduct a physical inspection.
